BAUMULLER 3.0404D 11.08 Processor Module

The BAUMULLER 3.0404D 11.08 is This high-performance control component is developed and produced by Germany’s Baumüller Group. It is a core unit of the b maXX series controller and peripheral system. As a key part of Baumüller’s automation ecosystem, it acts as a configurable motion control unit, SERCOS III/EtherCAT bus card or custom logic expansion board.

Category: Tag:

Description

BAUMULLER 3.0404D 11.08

Product Overview

The BAUMULLER 3.0404D 11.08 is This high-performance control component is developed and produced by Germany’s Baumüller Group. It is a core unit of the b maXX series controller and peripheral system. As a key part of Baumüller’s automation ecosystem, it acts as a configurable motion control unit, SERCOS III/EtherCAT bus card or custom logic expansion board.
It supports complex multi-axis algorithm operation, high-speed real-time data exchange and system safety monitoring. In Baumüller’s modular architecture, the module connects intelligent drives and upper industrial Ethernet systems. It ensures precise synchronization and real-time performance for multi-axis linkage.
This product follows Baumüller’s strict industrial design specifications. It adopts industrial-grade components and mature SMT processes. Its compact modular design supports DIN rail and backplane installation for easy cabinet integration. It is fully compatible with Baumüller b maXX servo drives, distributed I/O modules and HMI panels. It helps users build high-consistency, high-performance motion control systems for new CNC equipment and old device retrofits.

Product Parameters

Parameter Item
Parameter Specification
Product Model
Custom high-performance control module
Manufacturer
Baumüller (Germany)
Product Type
High-performance automation & motion control component
Product Series
b maXX series controller platform
Installation Method
DIN rail mounting / backplane plug-in (model-dependent)
Power Supply Voltage
24 VDC typical (backplane or external power)
Communication Interfaces
SERCOS III, EtherCAT, PROFINET (version-dependent)
Ingress Protection Rating
IP20 (indoor cabinet installation)
Operating Temperature
0°C to +55°C (industrial grade)
Certifications
CE, UL certified

Structure and Composition

This module adopts a high-density multilayer PCB as the core hardware. It uses 32-bit/64-bit MCU or DSP for high-efficiency computing. It integrates high-speed RAM for real-time data buffering and large-capacity Flash for firmware and parameter storage.
The module consists of three independent functional areas. The logic area executes RTOS scheduling, protocol parsing and user programs. The communication area connects external networks via isolated transceivers for SERCOS III and EtherCAT communication. The power area converts 24VDC input into stable internal voltages and provides isolated power for external peripherals.
It features a compact physical structure. Front-panel LED indicators display power, communication and fault status for quick on-site diagnosis. The suffix “L” indicates upgraded hardware with enhanced safety and logic processing functions.

Key Features and Advantages

1. Excellent Real-Time Performance and Synchronization

The hardware supports nanosecond-level IEEE 1588 synchronization and microsecond-level control cycles. It delivers precise, stable control for placement machines, CNC centers and precision automation equipment. It reduces trajectory errors and improves machining accuracy and consistency.

2. Industrial Reliability and Enhanced Safety

It adopts wide-temperature components and passes strict EMC tests. The fanless rugged structure resists vibration, dust and temperature changes for stable long-term operation. The “L” version complies with EN 61508 and EN 61800-5-2 standards. It supports STO, SS1 and other safety functions to secure equipment operation.

Application Fields

This module applies to high-precision and high-response automated machinery. In printing and papermaking, it synchronizes multi-color drums to ensure accurate color registration. In plastic processing, it controls multi-servo movements of all-electric injection molding machines for stable pressure and speed output.

Related Products

  • 3.0041F5.1: Similar series model with different computing performance, axis capacity and protocol support for function complementation.
  • 3.0124K: Standard non-L version without enhanced safety logic for common industrial applications.
  • BM5-O-CAN: b maXX 5000 CANopen module for distributed I/O expansion.
  • GSU Series: Baumüller servo drives that execute speed and torque control commands.
  • CAN-DI-16-01: 16-channel digital input module for on-site signal acquisition.
  • BM5-P-ETH: PROFINET/EtherNet/IP gateway for upper-layer network connection.

Installation and Maintenance

Pre-Installation Preparation

Ensure the cabinet meets IP20 standards with 0°C to +55°C ambient temperature. Secure the module on DIN rails or backplane slots firmly. Use shielded cables or optical fibers and implement single-end grounding to avoid electromagnetic interference.

Maintenance Guidelines

The high-integration design lowers daily maintenance workload. Check indicator status and terminal tightness every six months. Keep the cabinet clean and well-ventilated. Recheck connector locking after hardware modification. Replace faulty modules with qualified spares and return defective units to the factory for professional maintenance.
