1. Overview

2. Main Technical Parameters

Environmental Conditions

• Operating Temperature: -25～60°C for horizontal installation; -25～50°C for vertical installation
• Storage/Transportation Temperature: -40～85°C
• Relative Humidity: 5%～95% (non-condensing)
• Installation Method: Supports horizontal and vertical installation with no height restriction

3. Product Features

• Built-in RS232 Communication Interface: Equipped with one integrated RS232 serial interface to realize stable data communication with upper computers and peripheral equipment, ensuring convenient system signal interaction.
• Wide Temperature and Humidity Adaptability: Features a wide operating temperature range, enabling stable operation in harsh and complex industrial environments.
• High-density Compact Structure: Adopts a 37.5mm module spacing design, which effectively optimizes the internal space utilization of control cabinets and reduces equipment footprint.
• Comprehensive International Certifications: Certified by CE, UKCA, UL, DNV, CCS, LR, KR, ABS, BV, EAC and other global authoritative institutions, supporting application in various industries worldwide.
• Plug-and-Play Design: Complete with matched left and right end covers, supporting fast on-site assembly and commissioning to improve installation efficiency.
• Complete Software Ecosystem Support: Compatible with Automation Studio (upgraded to V4.3 version). Official E-CAD, M-CAD files and technical documents are available for download to facilitate system design, debugging and maintenance.

4. Structure and Composition

5. Application Fields

• Industrial Automatic Control: Serves as the backplane of compact PLC systems to build stable and efficient medium and small-scale industrial control systems.
• Machinery Manufacturing: Applied in cabinet integration of machine tools and automated production lines to support equipment automatic operation.
• Process Industry: Suitable for harsh working scenarios such as petrochemical, electric power and metallurgy industries with strict environmental requirements.
• Packaging Industry: Used for automatic control of various packaging machinery to ensure continuous and stable production.
• Automobile Manufacturing: Deployed as distributed control nodes in automobile production lines to realize precise workshop automation control.

6. Installation and Maintenance

6.1 Installation Guidelines

• Installation Direction: Both horizontal and vertical installation are supported. The maximum operating temperature is limited to 50°C for vertical installation.
• Installation Height: No height restriction for installation.
• Mechanical Size Requirement: The module spacing is 37.5mm, and corresponding reserved space on the DIN rail is required during installation.
• Accessory Installation: The matched left and right end covers must be installed correctly to protect internal bus connections and ensure system stability.
• Protection Specification: With IP20 protection grade, the module shall be installed in a clean control cabinet to avoid dust accumulation and liquid intrusion.

6.2 Wiring Precautions

• The I/O supply voltage is 24 VDC, and the actual contact load shall not exceed the rated 10 A to avoid equipment damage.
• There is no electrical isolation between the bus and the RS232 interface. Common ground processing and anti-interference measures shall be fully considered in system design to prevent signal interference.

6.3 Maintenance and Upgrade

• Hardware upgrade and firmware management can be realized via Automation Studio (V4.3 and above versions).
• Official E-CAD (electrical design drawings) and M-CAD (mechanical design drawings) files are provided to facilitate system integrated design, equipment transformation and daily maintenance.
• As a passive bus base module, it requires no special maintenance. Daily inspection focuses on checking connection firmness and cleaning contact surfaces to keep the module in good operating condition.
