CONTROL TECHNIQUES M750-02200090A 10101AB101
Product Overview
The CONTROL TECHNIQUES M750-02200090A 10101AB101 is a Unimotor HD industrial AC servo motor designed for precise motion control and reliable performance in automated machinery. It features a 67 mm frame, a 380–480 V AC voltage range, and a rated speed of 3000 RPM. An integrated 24 V holding brake and an absolute multi-turn encoder support accurate positioning and controlled stopping in industrial applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | AC Servo Motor |
| Product Series | Unimotor HD |
| Frame Size | 67 mm |
| Voltage Rating | 380–480 V AC |
| Rated Speed | 3000 RPM |
| Continuous Stall Torque | 2.55 Nm |
| Brake | 24 V holding brake |
| Feedback Device | Inductive SinCos multi-turn encoder |
| Encoder Interface | EnDat 2.1 |
| Output Shaft | Keyed shaft |
| Connection Type | Power and signal connectors, 90° rotatable |
Specifications are based on available product listings. Verify the complete configuration and electrical ratings against the manufacturer’s documentation before installation.
Main Features
- Accurate Position Feedback: The multi-turn encoder provides position feedback for compatible servo control systems.
- Integrated Brake: The holding brake helps maintain shaft position when the motor is stopped, subject to correct control and installation.
- Compact Design: The 67 mm frame supports integration into machinery with limited installation space.
- Flexible Connections: Rotatable power and signal connectors simplify cable routing in suitable installations.
- Thermal Reliability: Correct drive configuration and adequate cooling help maintain stable motor operation.
Construction and Working Principle
The motor consists of a stator, rotor, shaft, bearings, encoder, electrical connectors, and holding brake. Together, these components convert electrical energy into controlled rotary motion. The feedback device communicates motor position to a compatible drive, enabling accurate movement and coordinated machine operation.
Typical Applications
This servo motor is suitable for automated assembly equipment, packaging machinery, precision positioning systems, material handling, and other industrial applications that require controlled motion.
Installation and Maintenance
Secure the motor firmly and align the shaft with the driven mechanism. Confirm the drive compatibility, encoder interface, supply voltage, and brake wiring before commissioning. Follow the manufacturer’s instructions for grounding and parameter configuration.
Regularly inspect connectors, cables, mounting hardware, and shaft alignment. Also, monitor operating temperature and unusual vibration. Disconnect the power supply and follow appropriate electrical safety procedures before maintenance.
Supply and Replacement Support
We supply industrial automation spare parts for equipment maintenance and replacement projects. Contact us to confirm availability, product condition, and compatibility with your existing servo system.
