DEIF PSM-1 Generator protection relay

Description

DEIF PSM-1

This is a compact, cost-effective, and efficient single-channel generator protection relay designed for basic but critical protection and control tasks. It is primarily used in small and medium-sized generator sets, acting as a “smart guardian” for the generator, ensuring timely and reliable tripping in the event of a fault or unsafe operating conditions, thereby protecting the generator itself and connected equipment.

Core Features & Characteristics

1. Basic Generator Protection
   The PSM-1 integrates several of the most commonly used protection functions for generators:

   • Overcurrent Protection (50/51): Prevents generator damage caused by sustained excessive current.

   • Short Circuit Protection (50): Provides instant tripping for sudden, severe short-circuit faults.

   • Overvoltage/Undervoltage Protection (59/27): Monitors voltage to prevent damage to the generator and loads from abnormal voltage conditions.

   • Overfrequency/Underfrequency Protection (81O/U): Monitors frequency to ensure the generator operates at a stable speed.

   • Reverse Power Protection (32): For generators paralleled with the grid, prevents power feedback to protect the prime mover (e.g., a diesel engine).

   • Stator Earth Fault Protection (50N/51N): (Requires external current transformers) Detects earth faults in the stator windings.

2. Control & Measurement

   • Integrated Automatic Voltage Regulator (AVR): Features a built-in AVR function to stabilize the generator’s output voltage, ensuring power supply quality.

   • Engine Start Control: Can be configured to control the engine start sequence (e.g., start-up, cool-down shutdown).

   • Basic Measurement Functions: Displays key operating parameters such as voltage, current, frequency, and power.

   • Analog Inputs/Outputs: Supports analog signals for connecting temperature sensors, pressure sensors, etc., and can provide analog output signals.

3. User Interface & Communication

   • Front Panel Operation: Equipped with a clear display and navigation buttons for easy on-site parameter viewing and settings adjustment.

   • PC Tool Software: Configuration, monitoring, and fault analysis are made more convenient using DEIF’s PC tool software.

   • Optional Communication Modules: Supports various communication protocols (e.g., Modbus RTU, CANopen, J1939) for easy integration into broader monitoring systems.

4. Key Characteristics

   • Compact and Rugged: Small design suitable for switchboards with limited space. The robust housing is adapted for industrial environments.

   • Ease of Use: An intuitive interface and software make installation, setup, and operation straightforward.

   • High Reliability: Built on decades of DEIF experience in the marine and energy sectors, ensuring product stability and reliability.

   • Cost-Effective: Provides necessary protection and control functions at a reasonable cost, offering high value.



---

Typical Applications

The PSM-1 is suitable for various scenarios requiring basic generator protection and control, especially:

• Backup Power Systems: Standby diesel generator sets in commercial buildings, hospitals, data centers, etc.

• Small Power Plants: Small power stations operating in island mode or connected to the grid.

• Industrial Applications: Captive generator sets within factories.

• Marine Applications: Auxiliary generator sets on small vessels.
