Emerson KJ3209X1-BA1 DO module 8 channels 120230VAC
This high-performance 8-channel digital output module is designed to provide reliable on/off control in harsh industrial environments.
Emerson KJ3209X1-BA1 Digital Output Module – Product Description
1. Core Overview
The Emerson KJ3209X1-BA1 is a high-performance 8-channel digital output (DO) module designed to provide reliable switching control in demanding industrial environments.
2. Key Features & Specifications
| Feature | Specification Description |
|---|---|
| Product Type | Digital Output Module |
| Brand/Series | Emerson (part of its PACSystems series, originated from GE Fanuc) |
| Number of Channels | 8 independent, isolated output channels |
| Output Type | Relay Contact Output |
| Load Voltage | 120/230 VAC (Auto-sensing, Universal) |
| Contact Rating | 2A maximum per channel (at 30°C) |
| Isolation | Channel-to-channel group isolation (Typically in groups of 2 or 4 channels; please refer to the manual for specific grouping). Provides electrical isolation between groups and between groups and the logic side, preventing interference and high-voltage cross-talk. |
| Backplane Power | +5 VDC (from the RX3i backplate) for the module’s internal logic circuits. |
| Field Supply | Does not require a separate external DC power supply; the load voltage is provided directly by the user-supplied 120/230VAC source. |
| Status Indication | Each channel has a green LED indicator to display the output status (ON/OFF). |
| Connection Method | Via a removable screw terminal block for connecting field load wires and power wires, facilitating easy installation and maintenance. |
| Compatible Platforms | • PACSystems RX3i • PACSystems RX7i (Note: May require specific firmware versions or racks) |
3. Primary Functions
-
High Load Driving Capacity: Capable of directly driving AC loads up to 2A, controlling many industrial devices without intermediate relays.
-
Status Visualization: Independent LED indicators for each channel allow maintenance personnel to quickly diagnose field device status and module output status.
-
High Reliability: Designed for 24/7 continuous operation in industrial environments, with robust resistance to shock, vibration, and electrical noise.
4. Typical Applications
-
Motor Control: Starting/stopping motor contactors.
-
Valve Control: Opening/closing hydraulic or pneumatic solenoid valves.
-
Heater Control: Switching power to heating elements on or off.
-
Lighting Control: Controlling lighting systems in factories or areas.
-
Pump and Fan Control.
-
Used in various industries including manufacturing, water treatment, oil & gas, power generation, and transportation.
5. Installation & Usage
-
The module plugs into a PACSystems RX3i or RX7i Universal Backplane.
-
In the control program (typically ladder logic), each channel is turned ON or OFF by writing to the corresponding output address bit (0 or 1) assigned to the module.
