Description

UNIOP ETOP33C-0050-S UB-TOUCHGLASS

1. Product Overview

The UNIOP ETOP33C-0050-S UB-TOUCHGLASS is a high-performance Human Machine Interface (HMI) Operator Panel designed for industrial automation applications. It belongs to the UniOP eTOP series developed for machine control, process monitoring, and operator interaction. The device integrates a color touchscreen display, embedded control electronics, communication interfaces, and industrial-grade protection features to provide a complete visualization and control solution.

The serves as a core interface between operators and automation systems, enabling users to monitor equipment status, adjust operating parameters, manage system alarms, and establish communication with PLC controllers. Equipped with a 12.1-inch TFT color display, SVGA resolution, built-in Ethernet, USB support, and diverse flexible industrial communication options, it is perfectly adapted to medium and large-scale automation machines that demand high-definition visualization and stable, reliable operation.

2. Technical Specifications

Item	Description
Product Type	Industrial HMI Touch Panel
Display Type	12.1-inch TFT Color LCD
Resolution	800 × 600 pixels (SVGA)
Touchscreen Type	Resistive Touchscreen
Display Colors	Up to 64K colors
User Memory	64 MB
Power Supply	24 VDC (18–30 VDC)
Ethernet Interface	10/100 Mbps
USB Interface	USB Host
Serial Communication	RS-232 / RS-485 / RS-422
Front Protection	IP65
Mounting Type	Panel Installation
Programming Software	UniOP Designer
Application Area	Industrial automation and machine control

3. Main Features and Functions

3.1 Advanced Touchscreen Visualization

is equipped with a 12.1-inch TFT color graphic display featuring SVGA high resolution, which presents clear, detailed, and intuitive industrial process visualization. The professional resistive touchscreen is tailored for complex industrial scenarios, supporting stable operation even when operators wear gloves.

Operators can efficiently complete the following operations via the touchscreen interface:

Real-time viewing of machine operating conditions
Precise adjustment of production parameters
Dynamic monitoring of process variables
Quick access and query of alarm information
Intuitive control of connected automation equipment

3.2 Powerful Communication Capability

Designed with flexible and diverse industrial communication protocols, the eTOP40C can be flexibly connected to multiple types of automation equipment, adapting to different industrial network architectures. The built-in high-speed Ethernet interface greatly enhances device connectivity in modern automation systems, facilitating project downloading, remote equipment management, and real-time data exchange.

Core supported communication functions:

Multi-protocol PLC communication
Serial device connection and data transmission
Stable Ethernet networking communication
Expandable optional fieldbus modules

3.3 Rich HMI Application Functions

Supported by the professional UniOP Designer programming software, the eTOP40C integrates comprehensive advanced HMI functions, providing engineers with powerful and convenient tools to customize exclusive operator interfaces, optimize operation processes, and improve production efficiency.

Main available application functions:

Free graphical screen design and editing
Intelligent alarm classification and management
Historical event recording and query
Production recipe storage and management
Real-time trend data display and analysis
Automatic industrial data acquisition and sorting
Multi-level password protection and authority management
Multi-language switching for global application

4. Hardware Structure and Components

adopts an integrated modular hardware design, with compact internal structure and stable performance. The whole device consists of four core hardware modules:

4.1 TFT Display and Touch Module

The front-end integrated assembly integrates a high-definition color TFT screen and a durable resistive touch panel, providing accurate visual feedback and sensitive operator input functions. The large-size high-resolution display area can clearly present complex process graphics, real-time trend charts, and equipment layout diagrams, realizing intuitive industrial monitoring.

4.2 Embedded Processing Unit

The built-in high-performance industrial processor undertakes core tasks such as HMI program operation, multi-task communication management, and operator instruction processing. It provides stable and sufficient computing performance to ensure smooth operation of various visualization and control applications in complex industrial environments.

4.3 Communication Interface Board

The independent communication module is equipped with multiple universal interfaces, covering mainstream industrial communication methods. It supports efficient connection and data interaction with PLCs, engineering configuration equipment, industrial network systems and peripheral devices, realizing flexible equipment networking and function expansion.

4.4 Memory and Storage System

The built-in high-capacity independent memory is used to store HMI application programs, graphical interface resources, production recipe data, and system configuration parameters. The device can operate independently for a long time without external computer assistance, ensuring the continuity and stability of on-site industrial operation.

5. Application Fields

With its excellent stability, rich functions and strong compatibility, the UNIOP eTOP40C HMI panel is widely used in various industrial automation scenarios, covering manufacturing, process control, building automation and other fields.

5.1 Manufacturing Equipment

Automated assembly machines
Intelligent packaging systems
Automated production lines
Automatic inspection and testing equipment

5.2 Process Automation

Real-time industrial process monitoring
Online production parameter adjustment
Full-cycle equipment status visualization
Dedicated control system interactive interface

5.3 Building and Facility Automation

Intelligent HVAC control systems
Building energy consumption real-time monitoring
Public facility intelligent management interface

5.4 Industrial Machine Control

Textile industrial machinery
Food processing and production equipment
Material handling and conveying systems
Customized special automation machinery
