Description
UNIOP ETOP40B-0050
The UniOP ETOP40B-0050 is a human-machine interface (HMI) product of the eTOP Series 300 launched by Exor International S.p.A. Integrating advanced functions, reliable performance and exquisite appearance design, it serves as an ideal HMI solution for factory automation, building automation and other scenarios, and is specially developed for cost-sensitive application projects.
Key Specifications
|
Item
|
Parameters
|
|
Display Screen
|
5.7-inch TFT color display with LED backlight
|
|
Resolution
|
320×240 pixels (QVGA)
|
|
Color Depth
|
64K colors
|
|
Brightness
|
130 Cd/m² (typical value), adjustable brightness
|
|
Touch Screen
|
Analog resistive touch screen
|
|
User Memory
|
64 MB internal flash memory
|
|
Interfaces
|
10/100 Mbit Ethernet, USB, PC/printer port, PLC port (RS-232, RS-485, RS-422), auxiliary port
|
|
Power Supply
|
24V DC (18–30 Vdc), maximum current 0.55A
|
|
Weight
|
Approx. 1.0 kg
|
|
Operating Temperature
|
0–50°C
|
|
Storage Temperature
|
-20–+70°C
|
|
Humidity
|
5–85% (non-condensing)
|
|
Ingress Protection Rating
|
IP65 (front panel) / IP20 (rear panel)
|
|
Dimensions
|
187×147 mm; cutout size: 176×136 mm; depth: 45+4 mm
|
|
Body Color
|
White, black, silver (optional)
|
|
Certifications
|
CE, EN 61000-6-4/6-2 (EMC), UL 508 (Hazardous Location Class I, Division 2, Groups A-D)
|
Product Features
Advanced Vector Graphics: Supports multi-layer display and object transparency effects. It is compatible with various data display formats including numbers, texts, bar charts, analog meters and graphic images, and supports dynamic object attributes (show/hide) and TrueType fonts.
Powerful Communication Capability: Fully compatible with UniOP Designer 6 software, supporting more than 150 communication drivers and dual-driver communication function.
Network Functions: Built-in Ethernet port supports device communication, program downloading from Designer software and data retrieval from computers. The Ethernet-based UniNet network enables data sharing between multiple UniOP HMIs and provides data services via UniNet OPC Server.
USB Functions: The USB host port can be connected to a flash drive for application and firmware upgrades.
Expandable Fieldbus: Optional plug-in modules support mainstream fieldbus systems and networks, compatible with TCM and SCM modules.
Data Acquisition and Trend Monitoring: Supports real-time data acquisition and trend curve display. Trend data can be transmitted to host computers via Ethernet.
Recipe Storage: Recipe data can be transmitted through Ethernet or copied to flash drives via USB interface.
Multi-language Support: Compatible with multi-language applications including Far Eastern languages. The number of runtime languages is only limited by available memory. All text contents can be exported in Unicode format for convenient translation.
Human-Machine Interaction Functions: Equipped with a powerful macro editor for customized touch screen operations. It supports alarm and historical alarm lists, with alarm and event information printable or transmittable to host devices. It adopts 8-level password protection and supports report printing via serial port printers.
Hardware Advantages: Features an ultra-slim design with installation depth less than 50mm. It is standard-equipped with a real-time clock, screen saver and buzzer, and supports battery backup power supply.
Structure and Composition
According to official technical documents, the hardware structure of the eTOP306 mainly consists of the following components:
Display Module: 5.7-inch TFT color LCD screen with 320×240 resolution, 64K colors and LED backlight;
Front Panel: Analog resistive touch screen, 1 user LED indicator and 4 system LED indicators;
Multiple Interfaces: Ethernet port, USB port, PC/printer port, PLC port (RS-232/RS-485/RS-422) and auxiliary port (for fieldbus module connection);
Non-replaceable Rechargeable Lithium-ion Battery: Used for real-time clock backup power supply.
Application Fields
Factory Automation: Automatic control of production lines, monitoring and maintenance of mechanical equipment;
Building Automation: Various building automation system applications;
Complex Industrial Systems: Integration and intelligent management of industrial systems.
Installation and Maintenance
The product features a cutout size of 176×136 mm, a depth of 45+4 mm and an overall installation depth of less than 50 mm. It achieves IP65 ingress protection for the front panel and IP20 for the rear panel. For the complete installation and maintenance manual, please refer to the official technical documents released by Exor (e.g., Tech-note UniOP eTOP306).
