Extreme Networks E4G-400-DC Industrial Automation Module

EXTREME NETWORKS E4G-400-DC is an enterprise-class indoor wireless access point tailored for high-density network environments. Adopting 802.11ax Wi-Fi 6 technology and equipped with built-in integrated antennas, the device complies with FCC regulatory standards, applicable to network deployment scenarios in the United States, Puerto Rico and Colombia.

Category: Tag:

Description

Extreme Networks E4G-400-DC

Product Overview

EXTREME NETWORKS E4G-400-DC is an enterprise-class indoor wireless access point tailored for high-density network environments. Adopting 802.11ax Wi-Fi 6 technology and equipped with built-in integrated antennas, the device complies with FCC regulatory standards, applicable to network deployment scenarios in the United States, Puerto Rico and Colombia.
Featuring dual-band 4×4:4 MIMO radio design, the access point delivers stable and efficient wireless connection services, which can well support the access needs of a large number of terminal users, mobile devices and IoT equipment, adapting to complex and high-capacity enterprise network usage scenarios.

Technical Specifications

Parameter
Specification
Manufacturer
Extreme Networks
Device Type
Indoor Wi-Fi Access Point
Wireless Standard
IEEE 802.11ax / Wi-Fi 6
Radio Configuration
Dual Radio, 4×4:4 MIMO
Frequency Bands
2.4 GHz and 5 GHz
Antenna
Integrated internal antennas
Ethernet
Up to 5 GbE, plus 1 GbE interface
Power Supply Standard
IEEE 802.3at PoE
Typical Power Consumption
18 W
Maximum Power Consumption
22 W
Dimensions
229 × 229 × 48.15 mm
Weight
Approx. 1.45 kg
USB Interface
USB 3.0 Type-A
Deployment Scenario
Indoor
Regulatory Domain
FCC
In addition, the device supports OFDMA, MU-MIMO, beamforming and 160 MHz channel technology under 5 GHz frequency band. These core technologies effectively improve the capacity utilization rate and operating efficiency of modern wireless networks, and optimize the network carrying capacity in multi-terminal access scenarios.

Wireless Performance

The access point adopts dual-radio cooperation and 4×4:4 MIMO architecture, and is equipped with mainstream Wi-Fi 6 core technologies including OFDMA and beamforming. It greatly optimizes spectrum utilization efficiency, effectively solves the network congestion problem in multi-device simultaneous access scenarios, and significantly improves the overall wireless network operation performance.
In terms of antenna configuration, the device integrates dual-band and single-band omnidirectional antenna elements, which can realize full coverage of indoor wireless signals. Meanwhile, it is equipped with an independent Bluetooth Low Energy antenna, which can stably support Bluetooth low energy connection and various IoT intelligent application functions, expanding the application scope of wireless networking.

Hardware and Connectivity

The device is equipped with a high-speed RJ45 Ethernet interface, supporting up to 5 Gbps adaptive network speed, and is matched with an additional 1 GbE Ethernet interface to meet diversified wired connection and network transmission needs. The main Ethernet interface complies with the 802.3at Power over Ethernet standard, which can realize integrated network signal transmission and power supply through a single Ethernet cable, simplifying on-site deployment wiring.
In addition to PoE power supply, the device also supports 12 VDC external power supply mode. According to the installation specifications, when the external power supply is adopted, the PoE power supply function will be automatically disabled to ensure the safe and stable operation of the equipment.

Application Areas

As a high-performance indoor enterprise wireless access device, it is widely applicable to various indoor networking scenarios, including:
  • Corporate office scenarios
  • Education and campus facilities
  • Medical and health care environments
  • Commercial retail network scenarios
  • Hotel and catering service venues
  • Warehouses and commercial buildings
  • High-density wireless access areas
  • IoT equipment and mobile terminal connection scenarios
Benefiting from the excellent performance of Wi-Fi 6 architecture, the device is especially suitable for scenarios with a large number of concurrent access terminals and high requirements for spectrum efficient utilization, which can stably support large-scale wireless networking of enterprises.

Installation and Maintenance

The access point supports a variety of installation methods, and can be stably installed on qualified walls, solid ceilings, suspended ceilings, junction boxes and matching beams through special installation accessories. During installation, it is necessary to use the supporting standard mounting hardware correctly, and avoid excessive screwing that may cause deformation of the mounting bracket and affect the installation stability.
Before equipment installation, users need to confirm the FCC regulatory compliance, check the normality of Ethernet cables and PoE power supply capability, and complete the confirmation of installation mode and network management configuration parameters. In daily maintenance work, it is necessary to regularly inspect Ethernet connectors, mounting hardware, equipment ventilation area and running status indicators to ensure long-term stable operation of the equipment.
The enterprise has stopped the sale of this series of products in 2024 and launched new alternative products. For existing legacy network deployment scenarios, the device can still be used as replacement and maintenance equipment. Before deployment and use, users need to confirm the latest software support status and product lifecycle information to ensure compatibility and stability of subsequent operation.
