GE IS200EXHSG1AEC circuit board
GE IS200EXHSG1AEC is a specialized circuit board manufactured by General Electric (GE) designed for turbine control systems. It is also simply referred to as IS200EXHSG1A and belongs to the EX2100 Series, forming part of GE’s Excitation Control System.
🔧 Product Overview
The GE IS200EXHSG1AEC is a high-performance, specialized circuit board. Its primary functions are summarized below:
-
Primary Role: It serves as a Power Distribution Module within the GE Mark VIe control system, responsible for distributing power to various control components. Simultaneously, it provides drives for the excitation contactor and pilot relay.
-
Associated System: It is part of the EX2100 Excitation Control System, a series specifically designed for gas turbine control systems.
-
Board Type: Within the system, it is defined as an Analog I/O Board (TCQA), responsible for scaling and conditioning various analog signals read from terminal boards.
⚙️ Technical Specifications & Features
This board possesses the following key technical specifications and functional characteristics:
| Category | Specific Description |
|---|---|
| Relay Outputs | Provides 8 Form A (normally open) relay circuits for controlling user-supplied output loads. Each circuit has a switching capability of 4 Amps. |
| Signal Processing | Capable of scaling and conditioning multiple signals, including: LVDT inputs, servo valve outputs, thermocouple inputs, 4-20mA inputs/outputs, vibration inputs, relay driver outputs, pulse inputs, voltage inputs, and generator and line signals. |
| Safety Design | Each output point is isolated to ensure system safety and reliability. |
| Hardware Configuration | The board features hardware jumpers (e.g., J1, J2, J5, J6) used for function configuration, such as selecting milliampere output circuits and current ranges. |
| Communication Interface | Communicates with the STCA board in the system via a 3PL connector; sends and receives generator and line signals with the TCQC board via a JE connector. |
🏭 Primary Application Fields
This board is primarily used in the following industrial fields:
-
Turbine Control Systems: Plays a key role in control systems for gas and steam turbines, ensuring efficient and reliable system operation.
-
Industrial Automation: Widely used in various industrial scenarios requiring stable power distribution and control functions.
