Prosoft RLX2-IFH24E Gateway module

Description

Prosoft RLX2-IFH24E Gateway module

The SMART Module is a mature, reliable, and easy-to-use communication gateway that solves the most common multi-protocol coexistence issues in industrial sites, providing engineers using Rockwell CompactLogix systems with a standardized, efficient, and cost-effective solution for interconnecting with a large number of Modbus TCP devices.





Key Features & Functionality

1. Protocol Conversion:

   • Host Side: Integrates with the CompactLogix L2/L3 CPU via the backplane, using the EtherNet/IP protocol for communication.

   • Client Side: Provides a dedicated 10/100 Mbps Ethernet port for connecting to a Modbus TCP network and can operate as either a Modbus TCP Client (Master) or Server (Slave).

2. Seamless Integration:

   • Hardware: The module plugs directly into the right-side slot of a CompactLogix L2/L3 controller, requiring no separate power supply or wiring.

   • Software: It is configured within Rockwell’s RSLogix 5000 / Studio 5000 programming software using a pre-defined Add-On Profile (AOP). This makes the configuration process intuitive, similar to setting up a standard Rockwell native module, with no need for complex communication instructions.

3. Data Mapping:

   • The module creates a tag structure within the RSLogix 5000 project. Users simply define the required Modbus register addresses (e.g., 40001, 30001) in the configuration interface and map them to corresponding PLC tags (e.g., INT[100]).

   • This mapping allows PLC programmers to access data from remote Modbus devices as if they were accessing ordinary array tags, greatly simplifying programming.

4. High Performance:

   • Supports simultaneous communication with multiple Modbus TCP Servers (Slaves) when acting as a Client.

   • Supports high-speed data exchange, meeting the requirements of most real-time control applications.

Typical Application Scenarios

This module is widely used in scenarios requiring the integration of Rockwell control systems with third-party devices, such as:

• Drive Systems: Communicating with Modbus TCP-compatible Variable Frequency Drives (e.g., Schneider, Siemens, Danfoss) to read/write parameters like speed, frequency, and current.

• Power Monitoring: Connecting to intelligent power meters to read data such as voltage, current, power, and energy.

• Building Automation: Integrating with third-party controllers for HVAC systems, lighting control systems, etc.

• Process Instruments: Connecting to flow meters, level transmitters, temperature controllers, etc.

• Non-Rockwell HMI/SCADA: Allowing HMI/SCADA systems that support Modbus TCP to directly access CompactLogix PLC data through this module.

Technical Specification Summary

• Compatible Controllers: CompactLogix L2 and L3 series (e.g., 1769-L23E, 1769-L32E, 1769-L35E, etc.)

• Backplane Communication: EtherNet/IP

• Network Port: 1 x 10/100Base-TX RJ45 Ethernet port (for Modbus TCP)

• Protocol Support:

  • EtherNet/IP (for controller communication)

  • Modbus TCP (for external device communication)

• Operating Modes: Modbus TCP Client (Master) and/or Server (Slave)

• Configuration Method: Via Add-On Profile (AOP) in RSLogix 5000 / Studio 5000

• Power: Powered through the CompactLogix backplane
