Description
UNIOP ETOP407U301
1. Overview
2. Main Technical Parameters
2.1 Display & Touch System
|
Parameter Item
|
Specification
|
|---|---|
|
Display Type
|
Monochrome TFT
|
|
Display Size
|
5.7-inch (diagonal), display area: 115 × 86 mm
|
|
Resolution
|
1/4 VGA, 320 × 240 pixels
|
|
Backlight
|
White LED
|
|
Touch Screen Type
|
Resistive
|
2.2 Storage & Power Supply
|
Parameter Item
|
Specification
|
|---|---|
|
User Memory
|
32 MB (Flash Card)
|
|
Backup Battery
|
CR2430 lithium battery, 3V / 270 mA (non-rechargeable)
|
|
Supply Voltage
|
24 V DC (range: 18-30 V DC)
|
|
Maximum Current
|
0.6 A
|
2.3 Dimensions & Installation
|
Parameter Item
|
Value
|
|---|---|
|
Overall Dimension
|
187 × 147 mm
|
|
Panel Cutout Size
|
176 × 136 mm
|
|
Installation Depth
|
67 mm
|
2.4 Communication Interfaces
|
Interface Type
|
Description
|
|---|---|
|
Serial Port
|
RS-232 / RS-485 / RS-422 standard serial communication, supporting 20 mA current loop
|
|
PLC Port
|
Supported
|
|
Auxiliary Port
|
Supported
|
|
Fieldbus & Ethernet
|
Available with optional plug-in modules
|
|
Serial Programming Baud Rate
|
9600 – 38400 bps
|
3. Product Features
-
Cost-Effective Solution: Achieves a perfect balance of reliable quality and stable performance for budget-limited industrial projects.
-
Monochrome TFT Display with LED Backlight: Adopts a 5.7-inch monochrome TFT screen and white LED backlight, featuring low power consumption and long service life.
-
Resistive Touch Screen: Supports direct and intuitive touch operation for on-site control.
-
Versatile Communication Capabilities: Equipped with standard RS-232/485/422 and PLC ports; fieldbus and Ethernet functions are expandable via optional modules.
-
Large-Capacity User Memory: Built-in 32 MB Flash storage for storing application programs, production formulas and other on-site data.
-
Rich Software Functions: Supports vector graphics display, dual-driver operation, data acquisition & trend analysis, formula storage, alarm reminder, event logging, password protection and other practical functions.
-
Excellent Expandability: Compatible with industrial fieldbus systems and Ethernet networks through optional plug-in modules.
4. Structure & Composition
-
5.7-inch monochrome TFT display with built-in LED backlight module
-
Resistive touch screen overlay
-
Main control circuit board (integrated with 32 MB user memory and lithium battery backup circuit)
-
Aluminum alloy & engineering plastic housing (the front panel is reserved with a protective film position; PROT-03 disposable protective films are optional, 10 pieces per pack, specially designed for 5.7-inch eTOP series panels)
-
Rear communication interface area (RS-232/485/422, auxiliary port and PLC port)
5. Application Fields
-
Industrial process control
-
On-site equipment monitoring and operation
-
Industrial data acquisition and recording
-
Equipment fault alarm and display
-
Fieldbus network access (with optional matching modules)
6. Installation & Maintenance
6.1 Installation Method
6.2 Power Supply Requirements
6.3 Maintenance Precautions
-
Battery Maintenance: The mainboard is equipped with a non-rechargeable CR2430 lithium battery (3V / 270 mA) to maintain user memory data. Regular inspection and replacement are required.
-
Touch Screen Protection: PROT-03 disposable protective films are optional to prevent screen scratches and dust accumulation.
-
Dust & Moisture Prevention: For harsh industrial environments, it is recommended to adopt the eTOP05P model with coated electronic components or install additional protective films.
-
Communication Debugging: The serial programming baud rate ranges from 9600 to 38400 bps. Program downloading and equipment debugging can be realized via RS-232/485 interfaces.
