ZYGO SPM8020-9274-02 Measuring plate

Description

ZYGO SPM8020-9274-02

This is the Zygo ZMI-4004 series 4-axis VME64x measurement board (part number 8020-0500-01), commonly available in the market as the REVC version (also known as 8020-1500-01). This board is the core electronic module of the Zygo high-precision displacement measurement interferometer (DMI) system, primarily used in semiconductor manufacturing, nano-positioning systems, and other ultra-high precision motion control applications.



Key Technical Features

1. Four‑Axis Synchronous Measurement – Simultaneously acquires displacement data for X, Y, Z, and θ axes, compatible with Zygo 7712 laser sources for high‑accuracy displacement calculation.
2. Ultra‑High Resolution – Measurement resolution down to 0.15 nm, meeting sub‑nanometer positioning requirements.
3. High‑Speed Tracking – Maximum displacement tracking speed of 2.55 m/s, capable of capturing fast motion in real time.
4. Low Data Latency – Data age uncertainty in the nanosecond range, ensuring tight time synchronization across the four axes.
5. VME64x Standard – Implements a VME64x bus architecture for easy integration into industrial‑grade control platforms.
6. Compatibility – Works with Zygo 7712, 7713 laser heads and Zygo NewView, Maxim™ software suites, enabling automated measurement, real‑time SPC (process control), and Go/No‑Go inspection.

Typical Applications

• Semiconductor lithography and mask alignment systems
• Nanofabrication and MEMS (Micro‑Electro‑Mechanical Systems) testing
• High‑precision coordinate measuring machines (CMM) and optical inspection platforms
• Research laboratories requiring ultra‑high‑resolution displacement measurement
