Description

ZYGO SPM8020-9274-028020-0102-018020-0500-01ZMI-4004

The ZMI-4004 is Zygo’s high-performance 4-axis VME64x measuring board, a core component of the Zygo Displacement Measurement Interferometer (DMI) series, and is widely used in semiconductor manufacturing, nanotechnology, precision machining, and other scenarios with strict requirements for nanometer-level positioning and measurement.



• Technical Specifications
  • Resolution: 0.15 nm (dual‑channel plane‑mirror interferometer configuration)
  • Maximum Speed: 2.55 m/s (dual‑channel plane‑mirror interferometer configuration)
  • Data Rate: 10 MHz, data‑age uncertainty ±0.1 ns (synchronization between axes within the board)
  • Number of Axes: 4 axes per board, 6U VME64x electronic format
  • Applications:
    • Precision Machining: Real‑time monitoring of relative displacement between tool and workpiece to achieve nanometer‑level machining accuracy.
    • Nanotechnology & Research: Used in atomic force microscopes, scanning tunneling microscopes, and other high‑precision positioning platforms.
    • Industrial Automation: Provides high‑speed, low‑noise displacement measurement for advanced CNC machines, optical component manufacturing, and similar fields.
• System Integration: The ZMI‑4004 works together with Zygo laser sources (e.g., the 7712 series) and various interferometers, converting optical signals into high‑resolution displacement calculations. Its low data‑age uncertainty ensures multi‑axis synchronization, meeting the stringent requirements of next‑generation lithography and multilayer technologies.
