Description
Zygo ZMI-2001 8020-0210
It is a single-axis measurement board in the Zygo ZMI2000 series, designed specifically for high-precision displacement/position signal acquisition. It adopts Zygo’s proprietary interferometry technology and can operate on a 6U VME or ISA backplane. It is often used in conjunction with Zygo laser interferometers (such as the 6191-0584 series) to achieve real-time displacement, velocity, and time measurements.
1. Product Positioning
The ZMI‑2001 is the single‑axis measurement board within Zygo’s ZMI‑2000 series, designed for high‑precision displacement/position signal acquisition. It employs Zygo’s proprietary interferometric technology and can be mounted on a 6U VME or ISA backplane, typically paired with Zygo laser interferometers (e.g., the 6191‑0584 series) to provide real‑time displacement, velocity, and time measurements.
2. Key Technical Specifications
| Feature | Description |
|---|---|
| Measurement Axis | Single‑axis (X) |
| Measurement Range | Typically 0 – 50 mm (extendable depending on laser head and optics) |
| Resolution | < 1 nm (single channel) |
| Accuracy | ± 0.1 µm (under calibrated conditions) |
| Sampling Rate | Up to 10 MHz (compatible with Zygo 7712 laser head) |
| Interface | VMEbus (6U) or ISA; P2 connector for high‑speed parallel data; optional Ethernet/USB remote interface via Zygo software |
| Power Requirements | +5 V ± 5 % (3.5 A) and +12 V ± 10 % (0.1 A) |
| Operating Environment | Temperature 0 – +40 °C, humidity 10 – 90 % (non‑condensing), IP54 protection rating |
| Dimensions / Weight | Approx. 229 mm × 114 mm × 29 mm, weight ~1.2 kg (same mechanical envelope as ZMI‑2002) |
| Compatible Laser Heads | Zygo 6191‑0584, 7701/7701A/E, 7712 etc., 633 nm He‑Ne series |
| Software Support | Zygo VisionPro, Zygo Control – provides real‑time data streaming, coordinate transformation, and statistical analysis |
3. Main Functions
- Real‑time Displacement/Velocity Measurement – Directly outputs displacement, velocity, and time from interferometric signals, supporting high‑speed motion monitoring (> 2 m/s).
- Multi‑Channel Synchronization (optional) – Via the P2 connector, multiple boards can be daisy‑chained for synchronized multi‑axis measurement (implemented in the dual‑axis ZMI‑2002).
- Built‑in Laser Power Monitoring – Continuously monitors laser head output power to prevent drift‑induced measurement errors.
- Programmable Triggering – Accepts external synchronization signals (TTL, fiber) to trigger sampling, facilitating integration with motion‑control systems.
- Data Format – Provides 32‑bit displacement data, timestamps, and status words, compatible with high‑speed VME parallel bus or Ethernet transmission.
4. Typical Application Areas
| Industry | Example Use |
|---|---|
| Semiconductor Lithography | Stage displacement monitoring, overlay error control |
| Optical Component Manufacturing | Surface figure and thickness measurement of lenses, prisms |
| Precision Mechanics | Closed‑loop position feedback for high‑speed linear motors, piezo actuators |
| Research Laboratories | Nanometer‑scale displacement experiments, vibration analysis |
| Metrology & Quality Assurance | Length standard calibration in national metrology institutes |
5. Delivered Package
- ZMI‑2001 measurement board (8020‑0210‑01)
- Optional VME/ISA mounting bracket
- Power adapters (+5 V / +12 V)
- Interface cables (P2, VME)
- Quick‑start manual (OMP‑0403E)
- Software license (VisionPro / Control)
