Description
Zygo ZMI-2001 ESI PCB-IE- 144
This is a high-precision, low-noise single-axis interferometric measurement card, compatible with the VME/ISA platform, specifically designed for ESIPCB-I-E-144 semiconductor measurement systems to provide sub-nanometer resolution and ±0.1µm accuracy displacement detection.
- Purpose – A single‑axis interferometric measurement board designed for the ESI PCB‑I‑E‑144 position‑measurement application in semiconductor processing systems.
- Number of measurement axes – 1 axis (single‑axis version; the ZMI‑2002 provides two axes).
- Resolution – Better than 1 nm (the ZMI‑2002 family advertises “< 1 nm” resolution, and the ZMI‑2001 uses the same interferometric technology).
- Measurement accuracy – ±0.1 µm (identical to the ZMI‑2002 specification).
- Operating temperature range – 0 °C ~ +40 °C (specified for the ZMI‑2002 series).
- Power requirements – +5 V ±5 % 3.5 A and +12 V ±10 % 0.1 A (the ZMI‑2002 board’s power supply, which is the same architecture used by the ZMI‑2001).
- Interface – Compatible with 6U VMEbus and ISA back‑plane slots; can be installed directly into a standard VME/ISA chassis.
- Dimensions – Approximately 229 mm × 114 mm × 29 mm (the ZMI‑2002 mechanical envelope, which the ZMI‑2001 shares).
- Weight – About 1.2 kg (same as the ZMI‑2002 board).
- Enclosure material – Aluminum alloy, providing good heat dissipation and mechanical rigidity.
- Key features
- Utilises Zygo’s proprietary interferometric measurement technique to achieve sub‑nanometer resolution and low‑noise performance.
- Supplies independent real‑time position, time, and velocity data, which can be accessed via the P2 connector or directly over the VME bus.
- Offers a programmable synchronization signal for easy integration with external motion‑control systems.
- The simplified P2 interface allows one or multiple boards to be bus‑connected to a single servo card or motor controller.
- Designed for compact installation in a 6U VME or ISA backplane, minimizing the number of required slots.
