ABB 216AB61 HESG324013R101

This highly reliable, flexibly configurable 16-channel digital hybrid module is a key component of the underlying I/O network of ABB’s large-scale DCS control systems. It collects switching signals from field devices into the control system and executes switching control commands issued by the controller.



Key Features & Characteristics

1. Module Type: Digital Input/Output Module

   • Digital Input (DI): Receives switch status signals from field devices (e.g., push buttons, limit switches, relay contacts, proximity sensors). The signal state is “0” or “1” (i.e., “ON” or “OFF”).

   • Digital Output (DO): Sends switch control signals to field devices to operate equipment (e.g., relays, indicator lamps, solenoid valves, small contactors).

2. Channel Count: The module typically provides 16 channels. These channels can be configured via software as all input, all output, or in a mixed mode (some as inputs, some as outputs), depending on the firmware and configuration settings.

3. Electrical Characteristics:

   • Input Voltage: Typically 24V DC, the most common voltage level in industrial control.

   • Output Voltage: Also 24V DC for driving field devices.

   • Isolation: Channels are typically optically isolated from each other and from the backplane bus to enhance noise immunity and system safety.

4. Installation: It is an S800 I/O module that must be installed on a dedicated S800 I/O Base Unit (FUM), such as TU810v1 or TU810v2. A base unit can house one or several I/O modules and communicates with the central controller via a fieldbus (e.g., Profibus DP, Foundation Fieldbus) or ABB’s proprietary bus (e.g., S800 I/O Link).

5. Status Indication: The module front has LED indicators to display the status of each channel (e.g., “Power,” “Signal OK,” “Fault”), facilitating quick diagnosis for commissioning and maintenance personnel.

---

Associated Series & System

• Series: Advant Master / S800 I/O

• System: Primarily used in ABB’s IndustrialIT / 800xA system or the older Advant OCS (Open Control System).

• Controller: Works with AC 800M controllers (e.g., PM851, PM861) or the Advant Controller 400/500 series.

---

Typical Applications

This module is widely used in industrial process control and automation areas that require extensive handling of digital signals, such as:

• Chemicals & Petrochemicals: Valve control, pump start/stop status monitoring, level switch signal reading.

• Power & Energy: Circuit breaker status monitoring, protection relay signals, motor control circuits.

• Pulp & Paper / Metals: Production line equipment status monitoring, safety interlock signals, actuator control.

• Water Treatment: Pump control, level alarms, valve operation.
