ABB 3BHE004573R0 UFC760BE145 Single Loop Controller

Description

ABB 3BHE004573R0 UFC760BE145

The ABB UFC760BE145 is a highly advanced, microprocessor-based single loop controller module. It is a core component of ABB’s Freelance distributed control system (DCS) and MOD 30 product lines.

1. Key Features and Capabilities

• High-Performance Control: Executes complex control algorithms with high speed and accuracy, supporting PID control with advanced functionalities like auto-tuning, cascade, ratio, and feedforward control.

• Dual Processor Architecture: Features a powerful main processor for application execution and a dedicated communication processor for handling fieldbus protocols, ensuring reliable and deterministic performance.

• Extensive I/O Support: Connects to a wide variety of field instruments via its built-in communication ports. It supports analog inputs (AI), analog outputs (AO), digital inputs (DI), and digital outputs (DO) through connection to appropriate I/O terminal units (e.g., S800 I/O modules).

• Multiple Communication Protocols:

  • Integrated HART Communication: The UFC760BE145 variant includes a built-in HART multiplexer, allowing it to communicate with and manage HART-enabled smart field devices directly. This is a key differentiator from the UFC760BE142 model, which lacks this feature.

  • Fieldbus Support: Communicates over PROFIBUS DP (DPV1) and Modbus RTU protocols, enabling easy integration with motor starters, drives, and other field devices.

  • DCS Integration: Connects to the Freelance DCS via Controller Area Network (CAN).

• Large Display and Interface: Comes equipped with a high-contrast, graphical liquid crystal display (LCD) and a intuitive keypad for local operator access. This allows for clear visualization of process values, setpoints, alarms, and diagnostics directly at the controller.

• Flexible Configuration: Can be programmed and configured using ABB’s powerful Control

• Builder F engineering tool, which uses standardized function block diagrams (FBD) and instruction list (IL) languages per IEC 61131-3 standards.

• Robust and Reliable: Designed for harsh industrial environments with a wide operating temperature range and built-in diagnostics for high availability.

2. Technical Specifications (Summary)

• Ordering Number: 3BHE004573R0

• Product Type: UFC760BE145 (with HART)

• Mounting: Designed for mounting on a DIN rail within a PLC/DCS cabinet.

• Display: High-resolution graphical LCD with backlight.

• Communication Ports:

  • CAN (for DCS network)

  • PROFIBUS DP (DPV1)

  • Modbus RTU

  • HART multiplexer (integrated on the BE145 variant)

• Power Supply: Typically 24 V DC.

• Certifications: Designed to meet relevant international standards for industrial automation equipment (e.g., CE, ATEX for specific installations).

3. Typical Applications

The UFC760BE145 is ideal for precise control applications across various industries, including:

• Chemical and Pharmaceutical Processing

• Oil & Gas Production and Refining

• Power Generation and Water/Wastewater Treatment

• Pulp and Paper Manufacturing

• Food and Beverage Production

• Specific Use Cases: Temperature control loops, pressure regulation, flow control, level control, pH control, and acting as a smart subsystem controller within a larger plant network.

  Conclusion

  The ABB UFC760BE145 (3BHE004573R0) is a versatile and powerful single loop controller that combines the simplicity of a traditional controller with the advanced capabilities of a modern DCS. Its integrated HART support, multiple communication options, and robust design make it an excellent choice for critical control loops in demanding industrial automation environments.
