ABB 3BHE006412R0101 UFC762AE101 Control Module

Description

ABB 3BHE006412R0101 UFC762AE101

This high-performance industrial automation control module is widely used in industrial scenarios requiring precise motion control and high reliability. Produced by ABB, a leading global industrial automation manufacturer, this module is renowned for its outstanding performance, flexibility, and integration capabilities.



Core Functions

1. Multi-functional Servo Control:
   • Supports multiple control modes including speed control, position control, and torque control, meeting the demands of complex applications such as robotics and CNC machine tools.
   • Implements triple-loop precision control to ensure highly accurate motion trajectories.
2. Multi-axis Coordinated Control:
   • Capable of controlling and synchronizing multiple servo motors simultaneously, ideal for packaging machinery, automated assembly lines, and other equipment requiring complex synchronized motion.
3. High-Performance Processing and Feedback:
   • Equipped with a high-speed processor providing powerful computational capabilities for real-time responsiveness.
   • Integrated encoder interface connects to servo motor encoders for position feedback and closed-loop control, dynamically adjusting parameters to eliminate errors, with control accuracy reaching ±0.1% FS.
4. Robust Communication and Integration:
   • Supports multiple industrial communication protocols such as Modbus RTU, Profibus, and Ethernet; some models also support CAN bus.
   • Physical interfaces include RS485 and RS232, facilitating seamless integration with PLCs, HMIs, sensors, and other control systems to build comprehensive automation solutions.
5. Self-Diagnosis and Protection:
   • Features comprehensive self-diagnostic functions to monitor faults such as overload, overheating, and communication interruptions in real time, triggering alarms or protective mechanisms.
   • Supports redundant design, enhancing system availability and stability in critical applications.
6. User-Friendly Operation:
   • Motor parameters and control modes (e.g., PID, fuzzy control) can be easily configured using dedicated software, simplifying commissioning.
   • Supports remote monitoring and maintenance, reducing on-site operational costs.

Key Technical Specifications

• Model/Order Number: UFC762AE101 / 3BHE006412R0101
• Brand: ABB
• Supply Voltage: DC 24V (some sources also mention support for AC 100-240V or AC 220V)
• Input Signals: Analog (0-10V, 4-20mA), Digital (ON/OFF)
• Output Signals: Analog (0-10V), Digital (ON/OFF), Pulse signals
• Control Accuracy: ±0.1% FS
• Power Consumption: ≤2 W (typical value)
• Communication Interfaces: RS485, RS232, Modbus, Profibus, Ethernet
• Operating Temperature: -20°C to +60°C (or -10°C to +55°C, depending on specific model)
• Protection Rating: IP20
• Dimensions: 144 mm × 144 mm × 102 mm (common specification)
• Weight: Approximately 1.5 kg
• Mounting Method: DIN rail or wall mounting

Typical Application Scenarios

• Manufacturing: Industrial robot joint control, CNC machines, packaging and printing machinery.
• Energy Sector: Wind turbine pitch control, hydro/steam turbine control, power transmission and distribution monitoring.
• Infrastructure: Pump and valve control in water treatment systems, rail transit signaling systems.
• Heavy Industry: Metallurgical production lines (rolling mills, continuous casters), chemical process control.
• Other Fields: Medical equipment (CT scanner tables, surgical robots), environmental monitoring systems.
