Description
ABB 3BHE024415R0101 GVC714A101
Is an analog input/output (AI/AO) communication module
Key Functions and Features
Interface Functions:
1.Analog Input (AI): This module can receive analog signals from field sensors, such as:
4-20 mA current signal (most commonly used)
0-10 V voltage signal
Thermocouple or RTD signal (usually requires a specific signal converter)
2.Analog Output (AO): It can also send analog control signals to field actuators, such as a 4-20 mA current signal to control the opening of a control valve.
Communication Protocol:
This module typically functions as a slave device on a Profibus-DP network.
It collaborates with other I/O modules (such as digital input/output modules) in the S800 I/O station via the backplane bus. It transmits all I/O data to the master controller via the Profibus-DP fieldbus and receives output commands from the master controller.
3.Module Role:
This module is a communication master module or interface module. In an S800 I/O station, it is typically inserted into a specific slot on the base rack (usually the leftmost slot) and is responsible for managing data exchange and communication for the entire I/O station. A GVC714 module can manage multiple other types of S800 I/O modules within a station.
4.Key Parameters:
Operating Voltage: Typically 24V DC.
Communication Rate: Supports standard Profibus-DP communication rates up to 12 Mbps, automatically adjusting based on network conditions.
Diagnostic Functions: Powerful self-diagnostics and channel diagnostics detect faults such as disconnection, short circuit, and over-limit, and report status information to the main controller for easy maintenance.
Configurability: Parameters such as each channel’s type (AI or AO), range, and filter time constant can be flexibly configured using engineering software (such as ABB’s Control Builder).
Applications
Due to its high reliability and stability, this module is commonly used in demanding industrial process control environments:
- Power plants: Boiler control, turbine control, and water treatment systems.
- Chemical plants and refineries: Reactor temperature and pressure control, flow regulation, and component analysis.
- Paper mills: Pulp consistency control and vehicle speed coordination.
- Water and wastewater treatment plants: Pump control, pH adjustment, and flow measurement.
