Description

ABB CI543 3BSE010699R1

This is a high-performance fieldbus communication interface module. Its core function is to serve as a bridge between ABB S800 I/O modules and upper-level control systems (such as AC 800M controllers) or field networks, enabling conversion and data exchange between different communication protocols.





Key Features & Characteristics

1. Communication Protocol Conversion:

   • This is its primary function. It is designed to convert the local bus protocol of the S800 I/O (such as the S800 Link) into the standard Profibus DP-V1 fieldbus protocol.

   • This allows S800 I/O to be seamlessly integrated into automation systems using Profibus as the backbone network.

2. Operation as a Profibus DP Slave:

   • Within a Profibus network, the CI543 module acts as a slave device.

   • It is responsible for collecting process data from the connected S800 I/O modules (such as digital input/output, analog input/output, temperature measurement modules) and packaging this data for transmission over the Profibus network to the master station (typically a PLC or DCS controller).

   • Simultaneously, it receives control commands from the master station and relays them to the appropriate output modules.

3. Modular and Compact Design:

   • It features the standard S800 I/O module form factor and can be directly installed on an S800 I/O base unit (such as TU847, TU843, etc.).

   • This modular design facilitates easy configuration, installation, and maintenance.

4. High Performance and Reliability:

   • Engineered for industrial environments, it offers high immunity to interference and operational stability.

   • Support for the Profibus DP-V1 standard provides enhanced capabilities, such as acyclic data communication and alarm handling.

5. System Integration:

   • It is a key component of ABB’s automation solutions like System 800xA and Compact Product Suite.

   • It can be configured and managed uniformly through ABB’s engineering software (e.g., Control Builder).

Technical Summary

• Product Type: Communication Interface Module

• Product Series: ABB S800 I/O

• Primary Protocol: Profibus DP-V1

• Network Role: DP Slave

• Installation: Plugs into an S800 I/O base unit

• Supported I/O: Can manage a certain number of S800 I/O modules (the specific quantity depends on configuration and bus load).

• Diagnostics: Provides module status, communication status, and I/O channel diagnostics.

Typical Applications

The CI543 module is widely used in industrial automation fields that require high reliability and distributed I/O, such as:

• Process Industries: Chemical, Oil & Gas, Pharmaceuticals, Water Treatment.

• Power Industry: Power generation plants, Distribution systems.

• Manufacturing: Automotive, Food & Beverage, Pulp & Paper.

In these applications, it is typically installed in remote I/O stations in the field, connected to the central control room’s control system via a single Profibus cable. This significantly reduces wiring costs and enhances system flexibility and scalability.

Conclusion

The ABB CI543 3BSE010699R1 is a critical Profibus DP-V1 Interface Module. It is a reliable and efficient solution for connecting ABB’s advanced S800 series remote I/O to mainstream fieldbus networks. For users of ABB System 800xA or other systems supporting Profibus, this module is a vital component for implementing distributed control and system integration.

For more detailed technical manuals or configuration guides, it is recommended to visit the official ABB website or their technical support portal.
