Description

ABB GFD233A103 3BHE022294R0103

This is a fiber optic communication module, mainly used in ABB’s flagship AC 800M series programmable logic controller (PLC) and S800 I/O series remote I/O station.







Detailed Functions & Characteristics

1. Communication Protocol & Network:

   • It uses the Profibus DP-V1 protocol.

   • It forms part of ABB’s DrivesBus or Remote I/O Bus network. This is a master-slave network where the AC 800M controller acts as the master and the S800 I/O stations act as slaves.

2. Communication Medium & Advantages:

   • Fiber Optics: Compared to traditional copper cables, fiber optics offer significant advantages:

     • Immunity to Electromagnetic Interference: Completely unaffected by strong EMI from sources like power plants, variable frequency drives, and large motors, ensuring signal integrity.

     • Long-Distance Transmission: Supports much longer transmission distances (up to several kilometers) with minimal signal loss.

     • Electrical Isolation: Provides inherent electrical isolation between devices, preventing damage caused by ground potential differences.

     • High Bandwidth & Speed: Enables high-speed data exchange.

3. Module Role:

   • On the AC 800M controller side, it is typically installed on a communication interface module like the CI854 or CI855.

   • On the S800 I/O station side, it is installed on a terminal bus unit like the TB840.

   • It performs the conversion between electrical signals (from the controller or I/O modules) and light signals (transmitted over the fiber).

4. Application Fields:

   • This module is widely used in industrial environments demanding high reliability and noise immunity, such as:

     • Power Industry (Generation, Transmission, Distribution)

     • Oil & Gas

     • Chemical

     • Water & Wastewater Treatment

     • Pulp & Paper

     • Metals & Mining

---

Technical Parameters (Summary)

• Product Type: Fiber Optic Link Module

• Compatible Systems: ABB AC 800M Controller, S800 I/O System

• Communication Protocol: Profibus DP-V1

• Connector Type: ST or SC Fiber Optic Interface (ST is common for this model)

• Operating Wavelength: Typically 820nm or 1300nm (refer to the manual for specifics)

• Power Supply: Powered via its parent board (e.g., CI854, TB840).
