GE DS200SHVMG1AFE Technical Specifications
The GE DS200SHVMG1AFE is a high-performance I/O termination board designed for use in GE’s Mark VI Speedtronic turbine control system. This critical component serves as an interface between the turbine control system and various field devices, ensuring reliable operation in power generation applications.
Product Overview
The DS200SHVMG1AFE termination board is part of GE’s comprehensive Mark VI control system, which provides advanced monitoring and control for gas and steam turbines. This board is specifically engineered for harsh industrial environments with demanding reliability requirements.
Key Features
- High-density signal termination for Mark VI systems
- Robust design for industrial environments
- Compatible with various I/O signal types
- Designed for easy maintenance and replacement
- Supports redundant configurations for critical applications
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | DS200SHVMG1AFE |
| Manufacturer | General Electric (GE) |
| System Compatibility | Mark VI Speedtronic Turbine Control System |
| Board Type | I/O Termination Board |
| Input Voltage | 24V DC (typical) |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
| Storage Temperature | -40°C to +105°C (-40°F to +221°F) |
| Humidity Range | 5% to 95% non-condensing |
| Connector Types | High-density industrial connectors |
| Mounting | Rack-mounted in Mark VI enclosure |
| Certifications | UL, CE, RoHS compliant |
| Weight | Approximately 1.2 kg (2.65 lbs) |
| Dimensions | Standard Mark VI board size (varies by configuration) |
Functional Description
The DS200SHVMG1AFE serves as a critical interface between the Mark VI control system and field devices. It provides signal conditioning, isolation, and termination for various analog and digital I/O signals. The board is designed to handle the demanding requirements of turbine control applications, including vibration monitoring, temperature measurement, and control signal outputs.
Applications
The GE DS200SHVMG1AFE is primarily used in:
- Gas turbine power plants
- Steam turbine control systems
- Combined cycle power generation facilities
- Industrial turbine applications
- Power plant control and monitoring systems
Maintenance and Support
GE provides comprehensive support for the DS200SHVMG1AFE termination board, including technical documentation, spare parts, and repair services. Regular maintenance should be performed by qualified personnel following GE’s recommended procedures to ensure optimal performance and longevity.
Compatible Components
The DS200SHVMG1AFE works in conjunction with other Mark VI system components including:
- Control processors (DS200TCPDG1, etc.)
- Power supplies (DS200PSMG1, etc.)
- Communication modules
- Other I/O termination boards
Ordering Information
When ordering the DS200SHVMG1AFE or replacement parts, always specify the complete part number and revision level. Contact authorized GE distributors or GE Digital Energy for purchasing information and technical support.
Note: Specifications are subject to change without notice. Always consult the latest technical documentation from GE for critical applications.
