GE Fanuc IC693372-BG is a 24 VDC power supply module designed for the Series 90-70 programmable controller platform. It converts the incoming DC supply into the regulated voltages required by the PLC backplane and connected control hardware. Therefore, it provides an essential power foundation for Series 90-70 automation systems.

Product Highlights

This power supply is designed specifically for rack-based industrial control applications. It installs into the leftmost position of the Series 90-70 rack and connects directly to the rack backplane.

Furthermore, the unit provides three DC output rails: +5 VDC, +12 VDC, and -12 VDC. The main +5 VDC rail supplies the majority of the system logic load, while the auxiliary positive and negative rails support compatible circuit requirements. The total output capacity is rated at 90 watts.

Another advantage is its relatively wide input range. Although the nominal input is 24 VDC, the supply accepts approximately 18–32 VDC. As a result, it can accommodate normal variations in a 24 VDC industrial power system.

Technical Specifications

The three output ratings are individual maximums, while the combined output must remain within the 90 W total power rating. In addition, the documented protective limits include overvoltage and overcurrent protection.

Power Distribution and Protection

One important function is stable backplane power distribution. Once installed, the module supplies the regulated DC rails required by compatible Series 90-70 components.

Moreover, the design includes protective functions for abnormal electrical conditions. The +5 VDC output has an overvoltage protection range of approximately 5.7–6.7 V, while the documented maximum overcurrent limits are 26 A for the +5 V output, 4 A for the +12 V output, and 2 A for the -12 V output.

The power supply also provides a minimum 10 ms ride-through capability at 20 VDC. Consequently, short input disturbances do not necessarily cause an immediate loss of rack power. This feature can be valuable in industrial environments where stable control operation is important.

Rack Integration

The module uses a rack-mounted construction and connects through the Series 90-70 backplane. Its dedicated position at the left side of the rack helps separate the power section from the controller and I/O modules.

Additionally, one power supply can support a second rack when the overall load remains within the specified limits. A prewired extension cable can be used for this configuration. Therefore, the architecture can provide additional flexibility when a control system requires more rack space.

This capability can be especially useful during system expansion. Instead of immediately redesigning the entire controller architecture, engineers may be able to extend the existing rack arrangement while maintaining the original control platform.

Typical Applications

This DC power supply can support a variety of Series 90-70 automation installations, including:

• Industrial PLC control systems
• Factory automation
• Production machinery
• Process control
• Material handling
• Packaging equipment
• Manufacturing lines
• Equipment monitoring
• Legacy PLC maintenance
• Control system expansion

In particular, it is useful in applications where a 24 VDC plant supply is already available. Furthermore, its three regulated output rails make it suitable for the internal power requirements of compatible Series 90-70 hardware.

Installation and Maintenance

Before installation, technicians should verify the available DC input voltage, rack configuration, expected load, and grounding requirements. The input supply should remain within the specified 18–32 VDC range.

Proper grounding is also important. The Series 90-70 documentation recommends connecting the power supply ground terminal to the rack ground using an appropriate conductor. This helps reduce the possibility of electrical noise affecting controller operation.

Additionally, technicians should allow adequate airflow around the rack. When ambient temperatures exceed approximately 50°C, the maximum output power may need to be derated. Therefore, thermal conditions should be considered when the power supply is installed in a high-temperature cabinet.

During maintenance, inspect the power connections, grounding, rack connector, cooling conditions, and output status. If replacement becomes necessary, confirm the exact catalog number and electrical specifications before installation.

Reliable Choice for Legacy Systems

The Series 90-70 platform remains relevant in many established industrial installations. Consequently, compatible power supply modules can be important for keeping existing control equipment operational without replacing the entire PLC architecture.

Overall, this 24 VDC, 90 W power supply combines multiple regulated output rails, electrical protection, rack integration, and short-duration ride-through capability. Therefore, it can serve as a practical replacement or maintenance component for compatible Series 90-70 control systems.
