Rockwell ICS Triplex T9110 Module

Description

Rockwell ICS Triplex T9110

It is a triple redundant (TMR) programmable safety system controller





1. ‌Core Architecture: Triple Modular Redundancy (TMR) Fault Tolerance‌

   • ‌Fundamental Principle:‌ The system incorporates three identical, independent processing channels (including CPUs, I/O interfaces, power supplies, communication paths).
   • ‌Parallel Processing:‌ All three channels execute the same program and process identical input signals simultaneously.
   • ‌Voting Mechanism:‌ Critical system outputs (signals to final elements and status signals to operators) are determined by a “majority vote” (2oo3D) on the results from the three channels. A valid output is generated only if at least two channels agree. If one channel fails (Fail-Silent), the remaining two functional channels can maintain agreement and produce the correct output, ensuring continued safe operation.
   • ‌Fail-Safe:‌ A single point of failure does not cause a dangerous system failure or spurious shutdown, guaranteeing extremely high availability and safety.

2. ‌Key Characteristics:‌

   • ‌Exceptional Safety:‌ Achieves safety certifications up to SIL 3 (IEC 61508/61511), AK 6 (DIN V 19250), or Category 4 (EN 954-1) (specific level depends on application configuration). The TMR architecture and rigorous voting mechanisms are the foundation of this high safety integrity.
   • ‌High Availability:‌ The system continues safe operation without disruption even if one channel fails, minimizing unplanned downtime. Features a very long Mean Time Between Failures (MTBF).
   • ‌Online Maintenance:‌ Supports “hot-swap” replacement of key components (e.g., power supplies, I/O modules), enabling maintenance and repairs without interrupting the production process.
   • ‌Comprehensive Diagnostics:‌ Provides extensive self-diagnostics to rapidly detect and pinpoint hardware faults (at channel, module, or even component level). Fault information is clearly reported via maintenance panels or the host system for prompt corrective action.
   • ‌Flexible I/O System:‌
     • Supports a wide range of ‌Trusted TMR I/O modules‌ (Digital Input DI, Digital Output DO, Analog Input AI, Analog Output AO, Speed Monitoring RTD, etc.).
     • I/O modules typically also employ TMR design or incorporate safety voting mechanisms, matching the controller architecture.
     • Supports both local and remote I/O configurations.
   • ‌Multiple Communication Interfaces:‌ Provides standard communication interfaces (e.g., Serial, Ethernet) for data exchange with engineering workstations (programming/configuration), operator workstations (HMI), historians, or other control systems (e.g., DCS). Supported protocols typically include Modbus (RTU/TCP), OPC, etc.
   • ‌Dedicated Engineering Software:‌ Configured, programmed (using IEC 61131-3 languages like FBD, Ladder Logic, SFC), debugged, diagnosed, and maintained using the ICS Triplex ‌Trusted Toolset (TT)‌ software.

3. ‌Typical Application Scenarios:‌

   • Oil & Gas (Upstream, Midstream, Downstream): Emergency Shutdown Systems (ESD), Fire & Gas Detection Systems (F&G), Burner Management Systems (BMS), Compressor Control & Protection.
   • Chemical/Petrochemical: Process Safety Interlocks (PSI), Emergency Shutdown Systems (ESD), High Integrity Pressure Protection Systems (HIPPS), Reactor Trips.
   • Power Generation: Turbine Electronic Protection Systems, Boiler Safety Protection Systems (FSSS/BMS).
   • Other Critical Industries: Critical Safety Instrumented Systems (SIS) in processes such as Pharmaceuticals, Pulp & Paper, etc.

4. ‌Core Value Proposition:‌

   • ‌Protects Personnel, Assets, and the Environment:‌ Reliably executes safety functions under hazardous conditions.
   • ‌Maximizes Production Uptime:‌ Exceptional availability reduces losses from unplanned shutdowns.
   • ‌Reduces Total Lifecycle Cost:‌ Rapid diagnostics and online maintenance capabilities lower maintenance difficulty and costs.
   • ‌Compliance with Stringent International Safety Standards:‌ Meets mandatory functional safety regulatory requirements for process industries.

5. ‌Important Note:‌

   • ‌Obsolete Status:‌ The ICS Triplex T9110, along with the entire Trusted TMR controller family (including T8100, T8400, T8800, etc.), has been designated ‌Obsolete‌ by Rockwell Automation. New hardware is no longer sold, and direct support for this hardware and software is being phased out.
   • ‌Migration Paths:‌ Rockwell Automation recommends migration to safety solutions on its modern platforms: ‌GuardLogix‌ safety controllers within the ‌ControlLogix‌ platform or safety functions within the ‌PlantPAx DCS‌ system. Third-party companies also offer maintenance, repair, and partial migration services for existing Trusted systems.
