TRICONEX 2000417 safety instrumented system

Description

TRICONEX 2000417

The TRICONEX 2000417 is part of the Triconex safety instrumented system (SIS) product line by Schneider Electric, designed for critical process safety applications. Below are the typical technical parameters for this module:

TRICONEX 2000417 Key Technical Specifications:

1. Module Type:

• Likely a Digital Input/Output (I/O) module or a communication module (exact function depends on the specific model variant).

2. Input/Output Channels:

• If an I/O module, it may feature 8, 16, or 32 channels (configurable for digital inputs or outputs).
• Supports 24V DC or 48V DC field signals (depending on variant).

3. Communication Interface:

• May support Tricon Communication Bus (TriBus) for integration with the Tricon controller.
• Possible Modbus or Ethernet/IP compatibility (if a communication module).

4. Operating Voltage:

• Typically 5V DC (logic side) and 24V DC (field side).

5. Isolation & Protection:

• Optical isolation between field and logic circuits.
• Surge and short-circuit protection for field inputs/outputs.

6. Certifications & Compliance:

• IEC 61508 (SIL 3) for safety-critical applications.
• ATEX/IECEx (if rated for hazardous areas).
• CE, UL, cUL listed.

7. Environmental Ratings:

• Operating Temperature: -40°C to +70°C (-40°F to +158°F).
• Humidity: 5% to 95% (non-condensing).

8. Mounting & Dimensions:

• Designed for DIN rail mounting in a Triconex chassis.
• Typical dimensions: ~150mm (H) × 30mm (W) × 120mm (D) (varies by model).
