TRICONEX 3511
The Triconex 3511 is part of the Tricon Safety Instrumented System (SIS) by Schneider Electric, designed for high-integrity safety applications. Below are its key technical parameters:
General Specifications:
- Model: Triconex 3511 (often part of the Tricon v9/v10/v11 systems)
- Type: Digital Input Module (Safety I/O Module)
- Function: Monitors discrete (on/off) signals from field devices (e.g., switches, sensors) for safety-critical processes.
Key Technical Parameters:
1. Input Channels:
- Typically 16 or 32 channels (depending on configuration).
- Supports 24V DC or 48V DC field inputs (voltage range varies by model).
2. Input Voltage Range:
- Low Voltage (LV): 0–30V DC
- High Voltage (HV): 0–60V DC (check exact specs for the variant).
3. Isolation:
- Channel-to-Channel Isolation: Yes (prevents cross-talk/interference).
- Field-to-System Isolation: Reinforced isolation for safety.
4. Response Time:
- Typically <10 ms per channel (depends on configuration).
5. Diagnostics:
- Built-in fault detection (open wire, short circuit, etc.).
- Supports Triconex Triple Modular Redundancy (TMR) for fault tolerance.
6. Communication:
- Interfaces with the Tricon Main Processor via backplane.
- Compatible with Tricon v9, v10, v11 systems.
7. Certifications:
- SIL 3 (IEC 61508 / IEC 61511)
- TÜV, Ex (for hazardous areas, if applicable).
8. Operating Conditions:
- Temperature: -40°C to +70°C (industrial-rated).
- Humidity: 5–95% (non-condensing).
9. Redundancy:
- Supports TMR (2-out-of-3 voting) for high availability.
Applications:
- Emergency Shutdown Systems (ESD)
- Fire & Gas Systems (FGS)
- Turbine Control
- Critical Process Safety
