TRICONEX 9563-810

The Triconex 9563-810 is a safety system module manufactured by Triconex (now part of Schneider Electric), designed for use in high-integrity safety instrumented systems (SIS) and critical process control applications.

TRICONEX 9563-810 Technical Specifications

General Information

• Manufacturer: Triconex (Schneider Electric)
• Model: 9563-810
• Type: Power Supply Module
• Function: Provides redundant power supply for Triconex safety systems
• Compatibility: Designed for Tricon v9, v10, v11 and Tricon CX systems
• Safety Integrity Level (SIL): Supports SIL 3 systems

Electrical Specifications

• Input Voltage:
• • Nominal: 120/240V AC (auto-ranging)
  • Range: 90-264V AC, 47-63Hz
  • DC Input Option: 125V DC (optional)
• Output Voltage:
  • +5V DC: Primary logic power
  • +24V DC: Field power (for I/O modules)
• Power Capacity:
  • Total Output: Typically 200W (varies by configuration)
  • +5V DC Output: Up to 40A
  • +24V DC Output: Up to 6A
• Efficiency: >85% typical

Redundancy Features

• N+1 Redundancy: Supports parallel operation with another 9563-810
• Automatic Failover: Seamless switch to backup power supply
• Load Sharing: Balanced power distribution in redundant mode

Protection & Monitoring

• Protection Features:
• • Overvoltage protection
  • Overcurrent protection
  • Short-circuit protection
  • Over-temperature protection
• Monitoring Capabilities:
  • LED status indicators
  • Remote monitoring via Tricon system
  • Fault reporting to control system

Physical Specifications

• Dimensions: Standard Triconex module size
• Weight: Approximately 2.5 kg (5.5 lbs)
• Mounting: Installs in Triconex power supply rack
• Cooling: Convection cooling (fanless design)

Environmental Specifications

• Operating Temperature: -40°C to +70°C (-40°F to +158°F)
• Storage Temperature: -40°C to +85°C
• Humidity: 5% to 95% non-condensing
• Altitude: Up to 2000 meters (6562 feet) without derating

Certifications & Compliance

• Safety: UL 508, CSA C22.2 No. 14
• EMC: EN 61000-6-2, EN 61000-6-4
• Industrial: IEC 61131-2
• Hazardous Locations: ATEX, IECEx (optional)

MTBF & Reliability

• MTBF: >100,000 hours
• Design Life: 10+ years

Typical Applications

• Emergency shutdown systems (ESD)
• Fire and gas systems
• Turbine control systems
• Critical process control applications
