TRICONEX 9566-810 7400150-370 Safety Instrumented System

Description

TRICONEX 9566-810 7400150-370 3000540-380

The TRICONEX 9566-810 (7400150-370 / 3000540-380) is a module from the Triconex Safety Instrumented System (SIS) family, specifically part of the Trident™ or Triple Modular Redundant (TMR) control systems. Below are its key technical parameters:

General Specifications:

• Manufacturer: TRICONEX (Schneider Electric)
• Model Number: 9566-810
• Alternative Part Numbers:
  • 7400150-370
  • 3000540-380
• System Type: Safety Instrumented System (SIS) / Triple Modular Redundant (TMR)
• Function: Digital Input/Output Module (Exact function depends on configuration—verify datasheet for specifics).

Electrical Specifications:

• Input Voltage: Typically 24V DC (Confirm with datasheet, as some versions may differ)
• Operating Voltage Range: Likely 18-30V DC (Standard for Triconex modules)
• Current Consumption: Depends on configuration (Check datasheet for exact values)
• Isolation: High-voltage isolation for safety compliance (e.g., 1500V)

Communication & I/O Details:

• Communication Protocol: Proprietary Triconex TMR bus (for internal chassis communication)
• Number of Channels: Varies (e.g., 8/16/32 digital inputs or outputs)
• Input Type: Digital (Dry contact, wet contact, or voltage-sensing)
• Output Type: Relay or transistor-based (if applicable)
• Response Time: Typically <10 ms (for safety-critical applications)

Environmental & Certifications:

• Operating Temperature: -40°C to +70°C (typical for industrial modules)
• Humidity Range: 5% to 95% (non-condensing)
• Certifications:
  • IEC 61508 (Functional Safety)
  • SIL 3 (Safety Integrity Level)
  • ATEX / IECEx (if certified for hazardous areas)

Installation & Compatibility:

• Mounting: Designed for Triconex chassis (e.g., Trident, Tricon v9/v10/v11)
• Redundancy: Supports TMR (Triple Modular Redundancy) for fault tolerance
