TRICONEX MP3101 Main processor module

Description

TRICONEX MP3101

This is a high-performance, programmable main processor module manufactured by Triconex, a brand under Schneider Electric. It is a core component in the Tricon v9, v10, and v10.5 series of fault-tolerant control systems.

1. Core Function & Role
The TRICONEX MP3101 is a high-performance, programmable Main Processor Module manufactured by Triconex, a brand of Schneider Electric. It serves as the core component of the Tricon v9, v10, and v10.5 series fault-tolerant control systems.

2. Key Features

• Triple Modular Redundancy (TMR): Contains three separate processors, each executing the same program on its own channel. The system uses a two-out-of-three (2oo3) voting mechanism to detect and isolate a single channel fault, ensuring uninterrupted operation.

• High-Performance Processing: Offers faster processing speeds and larger memory capacity compared to its predecessors (e.g., MP3001), enabling it to handle more complex and high-speed control logic.

• Fault Tolerance: Designed for continuous operation in harsh industrial environments. The system can continue operating without interrupting process control even if one of the three channels fails, while alerting for maintenance.

• Comprehensive Diagnostics: Features robust built-in online diagnostics that continuously monitor the health of the module itself and the I/O modules, identifying potential issues early.

• Hot Swappable: Supports online hot-swap maintenance. This allows a faulty MP3101 module to be replaced without shutting down the entire control system or interrupting the production process.

• Communication Management: Manages communication between the Tricon chassis and external systems (e.g., DCS, HMI, Engineering Workstations), supporting various communication protocols and network interfaces.

3. Technical Specifications (Summary)

• Compatible Systems: Tricon v9, v10, v10.5 systems.

• Memory: Large user memory for storing application logic and variables.

• Processing Speed: High-speed scan cycles, suitable for critical control requiring fast response.

• Operating Temperature: Designed for a wide range of industrial temperatures.

• Installation Slot: Must be installed in the first slot (Slot #0) of the Tricon chassis.

4. Primary Applications

The MP3101 is primarily used in critical process control industries with high demands for safety and availability, such as:

• Oil & Gas: Emergency Shutdown (ESD) Systems, Fire & Gas (F&G) Detection Systems, Burner Management Systems (BMS).

• Chemical Industry: Process Shutdown (PSD) Systems, High Integrity Pressure Protection Systems (HIPPS).

• Power Generation: Turbine Control and Protection.

• Others: Railway signaling, offshore platforms, etc.

5. Position within the System

In a typical Tricon chassis:

• The MP3101 is installed in Slot 0, acting as the Main Processor.

• Other slots (e.g., Slots 1-3) may host Communication Modules for connection to external networks.

• The remaining slots are used for various I/O Modules, which interact with field sensors and actuators.

6. Important Notes

• Firmware Version: The firmware version of the MP3101 must be compatible with the overall Tricon system version. Different firmware versions may have variations in features and performance.

• Engineering Software: Programming, configuring, and diagnosing the MP3101 requires the dedicated Triconex engineering software—TriStation 1131.

• Product Discontinuation Notice: It is important to note that the Tricon v9, v10, v10.5 series (including the MP3101) has been declared End-of-Life by Schneider Electric. While spare parts are still available on the market, the newer-generation Tricon CX series is recommended for new projects.
