ABB G3EA HENF315754R1 IGBT power module

Description

ABB G3EA HENF315754R1

The ABB G3EA HENF315754R1 is a high-efficiency IGBT (Insulated Gate Bipolar Transistor) power module, commonly used in industrial drives, renewable energy systems, and traction applications. Below are its key technical parameters:

---

General Specifications:

• Manufacturer: ABB
• Model: G3EA HENF315754R1
• Type: IGBT Power Module (3rd Generation)
• Voltage Class: 1700V (typical for medium-voltage drives)
• Current Rating: ~300–600A (exact value depends on cooling & configuration)
• Configuration: Dual or HybridPack™ (Press-Pack IGBT)

---

Electrical Parameters:

Parameter	Value
Collector-Emitter Voltage (V<sub>CES</sub>)	1700V
Nominal Current (I<sub>C</sub> at 80°C)	~450A (varies with cooling)
Max. Pulsed Current (I<sub>CM</sub>)	900–1200A (short-time)
Gate-Emitter Voltage (V<sub>GE</sub>)	±20V (standard)
On-State Voltage (V<sub>CE(sat)</sub>)	~2.1V (typical at rated current)
Switching Frequency	1–10 kHz (optimized for efficiency)
Turn-On/Off Time	<1 µs (fast switching for reduced losses)

---

Thermal & Mechanical Parameters:

Parameter	Value
Junction Temperature (T<sub>j</sub>)	-40°C to +150°C
Thermal Resistance (R<sub>th(j-c)</sub>)	~0.05–0.1 K/W (depends on cooling)
Cooling Method	Liquid cooling or forced air
Module Weight	~2–3 kg (Press-Pack design)
Isolation Voltage (V<sub>ISO</sub>)	≥4000V
