TRICONEX 3381 communication module

Description

TRICONEX 3381

The TRICONEX 3381 is a communication module used in the Triconex Tricon and Trident safety systems (now part of Schneider Electric). It serves as a Triple Modular Redundant (TMR) communication interface, enabling connectivity between the Tricon system and external devices (e.g., DCS, PLCs, or HMIs).

---

TRICONEX 3381 Technical Specifications

1. General Information

• Model: 3381
• Type: TMR Communication Module (for Tricon v9/v10/v11 systems)
• Function: Provides Modbus TCP/IP, Modbus RTU, or TriStation Protocol communication.

2. Communication Protocols Supported

• Modbus TCP/IP (Ethernet-based)
• Modbus RTU (Serial RS-232/RS-485)
• TriStation Protocol (Schneider Electric proprietary)

3. Ports & Interfaces

• Ethernet Ports:
  • 2x 10/100 Mbps RJ45 ports (redundant communication)
• Serial Ports (Optional):
  • RS-232 (for point-to-point communication)
  • RS-485 (multi-drop communication)

4. Performance & Speed

• Data Transfer Rate:
  • Modbus TCP/IP: Up to 100 Mbps
  • Modbus RTU (RS-485): Up to 115.2 kbps
• Response Time:
  • <10 ms (typical for critical safety signals)

5. Redundancy & Reliability

• TMR Architecture (Triple Modular Redundancy)
• Hot-swappable (supports online replacement)
• Automatic failover in case of communication loss

6. Power Requirements

• Powered via Tricon backplane (no external power needed)
• Power Consumption: ~5W (typical)

7. Environmental Specifications

• Operating Temperature: -40°C to +70°C
• Humidity: 5% to 95% (non-condensing)
• Certifications: CE, ATEX, IEC 61508 (SIL 3), TÜV

8. Diagnostics & LED Indicators

• Status LEDs (Power, Communication Active, Fault)
• Built-in self-test (BIST) for fault detection

9. Safety & Compliance

• Safety Integrity Level (SIL): SIL 3 (IEC 61508)
• Certifications:
  • TÜV Rheinland
  • FM, CSA, ATEX (for hazardous areas)

10. Mounting & Dimensions

• Fits in Tricon chassis (9U/15U racks)
• Hot-swappable design

Typical Applications

• Safety Instrumented Systems (SIS)
• Process shutdown systems (ESD)
• Communication bridge between Tricon and DCS/SCADA
• Fire & Gas Systems (FGS)
