TRICONEX 3401 Digital Input Module

Description

TRICONEX 3401

The Triconex 3401 is a Digital Input (DI) Module designed for the Tricon v9, v10, and v11 safety systems. It is used to monitor field device statuses (e.g., switches, sensors) in critical safety applications. Below are its key technical parameters:

---

General Specifications

• Manufacturer: Triconex (Schneider Electric)
• Model: 3401
• Type: Digital Input Module (24V DC, 16-Channel)
• Safety Certification: TÜV, SIL 3 (IEC 61508)
• Compatibility: Tricon v9, v10, v11

Electrical Specifications

• Input Type: 24V DC Sinking/Sourcing (configurable)
• Number of Channels: 16 (isolated in groups)
• Input Voltage Range:
  • Nominal: 24V DC
  • Operating Range: 10–30V DC
• Input Current: Typically 5–10 mA per channel
• Response Time: < 10 ms (configurable filtering)
• Isolation:
  • Channel-to-Channel: 500V AC
  • Channel-to-System: 1500V AC

Environmental & Mechanical

• Operating Temperature: -40°C to +70°C
• Humidity: 5% to 95% non-condensing
• Mounting: Tricon chassis (hot-swappable)
• Weight: Approx. 0.5 kg

Diagnostics & Indicators

• LED Status per Channel:
  • Green (ON): Input active
  • Red (FLT): Fault (open wire, short circuit)
• Module-Wide LEDs:
  • PWR (Power): Module operational
  • OK (Health): Self-test status

Safety & Redundancy

• Fault Detection: Open-circuit, short-circuit, and overvoltage protection
• TMR Support: Triple Modular Redundancy (TMR) compatible
• Hot-Swappable: Yes (replace without system shutdown)

Applications

• Emergency Shutdown Systems (ESD)
• Fire & Gas Detection (F&G)
• Process Interlocks & Safety Loops
• Turbine/Compressor Control
