TRICONEX 3502E safety analog input module

Description

TRICONEX 3502E

The Triconex 3502E is a safety analog input module from the Tricon v9/v10/v11 series, designed for critical safety applications in industrial control systems. Below are its key technical parameters:

TRICONEX 3502E Technical Specifications:

1. Module Type:

• • Analog Input (AI) Module (Safety-rated)

2. Input Channels:

• • 16 channels (single-ended or differential configurable)

3. Input Signal Types:

• • Voltage: ±10V DC, 0-10V DC, 1-5V DC
  • Current: 4-20mA, 0-20mA (with external resistor for current-to-voltage conversion)

4. Resolution:

• • 16-bit (high-precision conversion)

5. Isolation:

• • Channel-to-channel isolation for noise immunity and safety

6. Accuracy:

• • Typically ±0.1% of full scale (depending on calibration)

7. Update Rate:

• • Configurable, typically 10ms per channel (varies based on system configuration)

8. Diagnostics & Safety Features:

• • Open-circuit detection
  • Over-range/under-range detection
  • Hardware fault detection (supports TMR – Triple Modular Redundancy)

9. Power Supply:

• • 24V DC (typical for Triconex systems)

10. Communication Interface:

• • Integrates with Tricon Controller (MP, Chassis) via TriBus

11. Certifications & Compliance:

• • IEC 61508 (Functional Safety)
  • SIL 3 (Safety Integrity Level) capable
  • ATEX/IECEx (for hazardous environments, if applicable)

12. Operating Temperature:

• • -40°C to +70°C (industrial-grade)

13. Mounting:

• • Installs in Tricon V9/V10/V11 chassis

Applications:

• Safety-critical process control (oil & gas, chemical, power plants)
• Emergency Shutdown Systems (ESD)
• Fire & Gas Detection Systems
