TRICONEX DO2401 Digital Output Module

The Triconex DO2401 is a Digital Output Module designed for high-reliability safety systems such as Tricon and Trident controllers.



·Tara(Sales Director)

·Tel: + 86-13806028623

·Whatsapp:+86-13806028623

·Email: ydf8801@163.com

·Ship to you via DHL/TNT/UPS/EMS/Fedex

Description

TRICONEX DO2401

The Triconex DO2401 is a Digital Output Module designed for high-reliability safety systems such as Tricon and Trident controllers. Below are its detailed technical specifications:


Triconex DO2401 – Digital Output Module – Technical Parameters

General Information:

  • Manufacturer: Schneider Electric (formerly Triconex)
  • Model: DO2401
  • Type: Digital Output Module (Triple Modular Redundant – TMR)
  • Compatibility:
    • Tricon v9, v10, v11
    • Trident Safety Systems

Electrical Specifications:

  • Output Type: 24V DC Sourcing (Triplicated Outputs)
  • Number of Channels: 8 channels (Independently controllable)
  • Output Current per Channel:
    • 0.5A (Continuous)
    • 2A (Inrush, <100ms)
  • Output Voltage Range: 20V – 30V DC
  • Load Compatibility:
    • Solenoid valves, relays, contactors, lamps, etc.
  • Isolation: 1500V AC (Channel-to-channel & field-to-logic isolation)

Redundancy & Safety Features:

  • Triple Modular Redundancy (TMR): Three independent output circuits per channel for fault tolerance.
  • Voting Logic: 2-out-of-3 voting for fail-safe operation.
  • Diagnostics:
    • Open-load detection
    • Short-circuit protection
    • Overcurrent shutdown
  • Hot-Swappable: Supports online replacement without system shutdown.

Environmental & Mechanical Specifications:

  • Operating Temperature: -40°C to +70°C (-40°F to +158°F)
  • Storage Temperature: -50°C to +85°C (-58°F to +185°F)
  • Humidity: 5% to 95% (non-condensing)
  • Vibration/Shock Resistance: Complies with IEC 60068-2-6 (vibration) & IEC 60068-2-27 (shock)
  • Mounting: Rack-mounted (Triconex chassis)

Certifications & Compliance:

  • IEC 61508 (Functional Safety)
  • SIL 3 (Safety Integrity Level)
  • CE, ATEX, UL, CSA (Depending on region)

Typical Applications:

  • Emergency Shutdown Systems (ESD)
  • Fire & Gas Systems (FGS)
  • Turbine Control & Bypass Systems
  • Process Automation in Oil & Gas, Power, Chemical Plants

Comparison with Other Triconex DO Modules:

Model Type Channels Output Current Key Feature
DO2401 24V DC Sourcing 8 0.5A (2A inrush) TMR, SIL 3
DO2201 24V DC Sinking 8 0.5A TMR, High-density
DO3401 48V DC Sourcing 8 0.5A High-voltage output
